SMART Board Interactive Display Panels

SMART Board GX

Tech & Learning 2024 Best of Show Winner

The SMART Board GX is the affordable and well-equipped option for any classroom. With up to 40 touch points, Object awareness™, and 4K Ultra HD resolution, the GX brings added security and reliability for a value that can’t be beat. Available in 65”, 75”, and 86” sizes.

SMART Board MX

Significant Value and Essential Collaborative Features

The SMART Board MX is a digital whiteboard complete with a Chromium™ web browser. Available in 65″, 75″ and 86″ sizes with 4K Ultra HD resolution, the MX series holds great value for schools that need an interactive display on a tight budget.

SMART Board RX/QX

The Newest Member of the SMART Board Family

SMART Board RX/QX features Tool Explorer and SMART ink technology, high-performance display, and an on-board operating system, iQ, that makes it easy to deliver content on the panel or interact with any student device.

Compare SMART Board Displays for Education

Software	GX (V3) series	MX (V5) series	RX series
SMART Notebook®	Included	Included	Included
SMART Notebook Plus	Optional	Optional	Optional
Lumio™	Optional	Optional	Optional
SMART Product Drivers and SMART Ink®	Included	Included	Included
SMART Remote Management	Optional	Subscription for the length of the warranty	Subscription for the length of the warranty
Embedded features	Digital whiteboard Web browser Screen sharing Input select File manager Overlay Split screen Picture-in-picture (PIP) with touch pass-through Interactive widgets App library	Digital whiteboard Chrome™ browser Screen sharing Google Play™ store Personalized home screen and settings Input select Split screen PIP with touch pass-through Interactive widgets Templates, graphic organizers, and manipulatives File and app libraries Google Drive™ and OneDrive™ access	Digital whiteboard Chrome browser Screen sharing Google Play store Personalized home screen and settings Input select Split screen PIP with touch pass-through Interactive widgets Templates, graphic organizers, and manipulatives File and app libraries Environmental sensors dashboard Tool Explorer™ Image Editor Google Drive and OneDrive access
Display	GX (V3) series	MX (V5) series	RX series
Screen sizes (diagonal)	65″ \| 75″ \| 86″	55″ \| 65″ \| 75″ \| 86″	65″ \| 75″ \| 86″
Resolution	4K UHD (3840 × 2160)	4K UHD (3840 × 2160)	4K UHD (3840 × 2160)
Refresh rate	60 Hz	60 Hz	60 Hz
Lifespan	≥ 50,000 hours	≥ 50,000 hours	≥ 50,000 hours
LCD quality	Grade A	Grade A	Grade A
Brightness¹	400 cd/m²	55″: 300 cd/m² 65″, 75″, 86″: 400 cd/m²	490 cd/m²
Display response time	≤ 8 ms	≤ 8 ms	≤ 8 ms
Glass	Full heat-tempered \| Anti-glare \| Bonded	55″: Full heat-tempered \| Anti-glare 65″, 75″, 86″: Full heat-tempered \| Anti-glare \| Bonded	Optically bonded \| Anti-glare \| Anti-fingerprint \| Heat-tempered
Sensors	Ambient light \| Infrared	Ambient light \| Infrared	Proximity \| Ambient light \| Infrared \| Room temperature \| Humidity \| Equivalent carbon dioxide (eCO2) \| Volatile organic compound (VOC) \| Particulate Matter (PM_2.5)
Speakers	2 integrated 20 W speakers	55″: 2 integrated 15 W speakers 65″, 75″, 86″: 2 integrated 20 W speakers	Integrated soundbar featuring two 20 W speakers and a 15 W subwoofer
Microphone	N/A	Integrated linear six-microphone array with support for onboard acoustic echo cancellation	Integrated linear eight-microphone array with visual mute status indicator and support for onboard acoustic echo cancellation
QR code sign in to a SMART Account
NFC sign in to a SMART Account
Convenience buttons	Power \| Home \| Volume \| Freeze frame	Power \| Home \| Volume \| Input select \| Screen shade \| Freeze frame	Power \| Home \| Volume \| Microphone mute \| Freeze frame
¹Brightness of individual displays can vary.
Touch and interaction	GX (V3) series	MX (V5) series	RX series
Touch technology	Advanced infrared	HyPr Touch™ with Advanced IR	HyPr Touch with Advanced IR
Frame rate	≥ 125 Hz	≥ 200 Hz	≥ 300 Hz
Touch response time	≤ 8 ms	≤ 5 ms	≤ 4 ms
Accuracy	1 mm	1 mm	1 mm
Minimum object size	2 mm	2 mm	2 mm
Continuous touch points (fully differentiated)	Up to 40 touch points (OS dependent)	Up to 40 touch points (OS dependent)	Up to 40 touch points (OS dependent)
Interaction types	Pens \| Touch \| Gesture \| Palm erase	Pens \| Touch \| Gesture \| Palm erase	Pens \| Touch \| Gesture \| Palm erase \| Erase \| Fine erase \| Tool Explorer tools
Eraser, pen, and touch differentiation (simultaneous tool differentiation)	²
Continuous pen, touch, and erase (continuously write, move, and gesture and erase simultaneously)	²
Eraser types	Palm erase	Palm erase	Palm erase \| Fine erase \| Eraser blocks
Azimuth erasing	N/A	N/A	Eraser blocks
Palm rejection	Non-writing hand in Android™ whiteboard	N/A	Writing and non-writing hand
Object recognition	³
Pressure-sensitive ink
Automatic pen color recognition
Unique Pen ID support	2: Windows® and macOS, when using a finger to write or draw	2: Windows and macOS, when using a finger to write or draw	Unlimited
Tools included	Pens (×2)	Pens (×2)	Stylus with multi-color select and fine eraser (×2) Erasers with angle of orientation (×2)
Tool holders	Magnetic \| Frame‑mounted	Magnetic \| Frame‑mounted	Intelligent \| Magnetic \| Frame‑mounted
²A connected computer with SMART Product Drivers installed is required. Only supported in SMART Notebook and SMART Ink. ³When connected to a computer with SMART Product Drivers installed
Embedded Android OS	GX (V3) series	MX (V5) series	RX series
Operating system	Android version 11.0 (upgradable to Android 13.0)⁴	Android version 13.0 (forward compatible)	Android version 13.0 (forward compatible)
CPU	Quad-core	Octa-core	Octa-core
Memory	8 GB DDR4	8 GB DDR4	8 GB DDR4
OS architecture	32-bit (Android 11) 64-bit (Android 13)	64-bit	64-bit
Storage	64 GB	64 GB (up to 576 GB)	64 GB (up to 576 GB)
User interface	4K UHD (3840 × 2160)	4K UHD (3840 × 2160)	4K UHD (3840 × 2160)
Updates	Over‑the‑air (OTA)	Automatic OTA	Automatic OTA
⁴Update available in 2024 by OTA.
Network connectivity	GX (V3) series	MX (V5) series	RX series
Wired	RJ45 (×2) 1000BASE-T	RJ45 (×2) 1000BASE-T	RJ45 (×2) 1000BASE-T
Wi-Fi	IEEE 802.11ax (Wi-Fi 6) supporting WEP, WPA, WPA2, WPA3 PSK, and 802.1X EAP authentication protocols Wi-Fi hotspot	IEEE 802.11ax (Wi-Fi 6e) supporting WPA, WPA2, WPA3 PSK, and 802.1X EAP authentication protocols Wi-Fi hotspot	IEEE 802.11ax (Wi-Fi 6e) supporting WPA, WPA2, WPA3 PSK, and 802.1X EAP authentication protocols Wi-Fi hotspot
Bluetooth®	5.0 dual mode	5.2 dual mode	5.2 dual mode
Classroom connectivity	GX (V3) series	MX (V5) series	RX series
Number of student devices connected to the display	9	40+ through any web browser, no sign in required⁵	40+ through any web browser, no sign in required⁵
Whiteboard broadcast	N/A	200 (unlimited)⁵ Live content and annotation updates	200 (unlimited)⁵ Live content and annotation updates
Student device collaboration activities
Whole-class collaboration tools	N/A	Two-way annotation: ink and text tool to whiteboard canvas with student attribution Polling and voting Checks for understanding Questioning and reflection exercises Freeform or categorized brainstorming and ideation Activating prior knowledge exercises	Two-way annotation: ink and text tool to whiteboard canvas with student attribution Polling and voting Checks for understanding Questioning and reflection exercises Freeform or categorized brainstorming and ideation Activating prior knowledge exercises
Device connection options (screen share)	AirPlay Chromecast™ Miracast Screen share app Web app Screen share any device on the same network:	AirPlay Chromecast Miracast Screen share app Web app Screen share any device, any network:	AirPlay Chromecast Miracast Screen share app Web app Screen share any device, any network:
Device connection options (whiteboard)	N/A	Live whiteboard broadcast through any web browser Contribution access through any web browser, including collaboration activities	Live whiteboard broadcast through any web browser Contribution access through any web browser, including collaboration activities
Teacher control options (screen share)	Moderated with 9× grid view	Unmoderated Moderated with 4× grid view	Unmoderated Moderated with 4× grid view
Teacher control options (whiteboard)	N/A	Teacher-led navigation Student-paced navigation Pause contributions to collaborative whiteboard canvas	Teacher-led navigation Student-paced navigation Pause contributions to collaborative whiteboard canvas
⁵Unlimited connections available to whiteboard. Speed and function subject to individual network capabilities.
Inputs	GX (V3) series	MX (V5) series	RX series
OPS PC accessory slot
microSD slot
HDMI®	(×3) HDMI 2.0 with HDCP 1.4 and HDCP 2.2 support	(×4) HDMI 2.1 4K @ 60Hz with HDCP 1.4, HDCP 2.3, ARC, and eARC support (ARC and eARC support are available only with the HDMI 2 input.)	(×4) HDMI 2.1 4K @ 60Hz with HDCP 1.4, HDCP 2.3, ARC, and eARC support (ARC and eARC support are available only with the HDMI 2 input.)
Display Port 1.2
VGA video
Stereo 3.5 mm (variable)
RS-232 (DB-9 connector)
RJ45 (LAN IN)
USB Type‑C	(×2) Front: 15 W power delivery	(×2) Front: 27 W power delivery; Side: 65 W power delivery	(×2) Front and side: 65 W power delivery; Top: 15 W power delivery
USB 2.0 Type-A
USB 3.2 Gen 1 Type‑A	(×4)	(×4)	(×4)
USB 2.0 Type-B	(×2)
USB 3.2 Gen 1 Type‑B		(×4)	(×4)
Outputs	GX (V3) series	MX (V5) series	RX series
HDMI	HDMI 2.0 with HDCP 1.4 and 2.2 support	HDMI 2.1 4K @ 60Hz with HDCP 2.3 support	HDMI 2.1 4K @ 60Hz with HDCP 2.3 support
USB Type‑C		4.5 W power delivery	4.5 W power delivery
Stereo 3.5 mm (variable)
S/PDIF optical (fixed)
RJ45 (LAN OUT)
OPS accessory slot	GX (V3) series	MX (V5) series	RX series
OPS support	SMART PCM or AMG1	SMART PCM	SMART PCM
OPS power delivery	90 W	85 W	100 W
Installation	GX (V3) series	MX (V5) series	RX series
VESA mounting points
Wall mount bracket	Optional	Optional	Optional
Included cables and accessories	Pens (×2) Remote control Country-specific power cable USB Type-A to Type-B cable	Pens (×2) Remote control Country-specific power cable USB Type-A to Type-B cable USB Type-C cable	Stylus with multi-tool select and fine eraser (×2) Erasers (×2) Remote control Country-specific power cable USB Type-A to Type-B cable USB Type-C cable
Certification and compliance	GX (V3) series	MX (V5) series	RX series
US / Canada	cULus \| FCC \| ISED \| TSCA \| CONEG Packaging \| Proposition 65	UL \| FCC \| ISED \| TSCA \| CONEG Packaging \| Proposition 65	FCC \| ISED \| TSCA \| CONEG Packaging \| Proposition 65
EU / EEA / EFTA / UK	CE \| UKCA \| LVD \| CB \| EMCD \| RED \| REACH \| RoHS \| Battery \| WEEE \| Packaging \| POP \| Ecodesign	CE \| UKCA \| LVD \| CB \| EMCD \| RED \| REACH \| RoHS \| Battery \| WEEE \| Packaging \| POP \| Ecodesign	CE \| UKCA \| LVD \| CB \| EMCD \| RED \| REACH \| RoHS \| Battery \| WEEE \| Packaging \| POP \| Ecodesign
Australia / New Zealand	RCM	RCM	RCM
Performance standards	ENERGY STAR® \| HDMI \| HDCP	ENERGY STAR \| HDMI \| HDCP	ENERGY STAR \| HDMI \| HDCP
Product availability may vary by region. \| This product has received additional certifications not listed here.

Revolutionize teaching with SMART interactive flat panels. With leading touch technology that fosters collaboration through simultaneous tool differentiation and a suite of interactive apps, SMART is your one-stop-shop for classroom innovation.

Choose the best SMART display for your classroom, all complete with high-tech features.

SMART Board Interactive Display Panels

SMART Board GX

Tech & Learning 2024 Best of Show Winner

The SMART Board GX is the affordable and well-equipped option for any classroom. With up to 40 touch points, Object awareness™, and 4K Ultra HD resolution, the GX brings added security and reliability for a value that can’t be beat. Available in 65”, 75”, and 86” sizes.

SMART Board MX

Significant Value and Essential Collaborative Features

The SMART Board MX is a digital whiteboard complete with a Chromium™ web browser. Available in 65″, 75″ and 86″ sizes with 4K Ultra HD resolution, the MX series holds great value for schools that need an interactive display on a tight budget.

SMART Board RX/QX

The Newest Member of the SMART Board Family

SMART Board RX/QX features Tool Explorer and SMART ink technology, high-performance display, and an on-board operating system, iQ, that makes it easy to deliver content on the panel or interact with any student device.

Compare SMART Board Displays for Education

Key Features

Touch designed for learning

SMART panels hold up to 40 points of interaction for seamless collaboration. Plus, with Object awareness™, there’s no need for technology distractions, as students and teachers can with write with pens, move with fingers, and erase with palms.

SMART Ink

Annotate effortlessly by using digital ink tools on both Windows and Mac systems. SMART Ink’s best-in-class tools allow educators to markup presentations and lessons, all without the delays and screen freezes.

iQ Technology

Go Wire-Free with SMART iQ Technology

Seamlessly connect your lesson content, interactive display, student devices, and pedagogy in a few simple steps. All SMART boards that are equipped with iQ technology have the ability to be used as a standalone device with whiteboard technology, no need for any additional PC or devices connections.

SMART Notebook Plus

SMART Notebook Just Got Better

Notebook Plus brings web-based features and game-based activities with student device integration and formative assessment tools. All boards come with access to SMART Notebook, but schools can opt to subscribe to SMART Notebook Plus to access additional features.

Notebook Player/Whiteboard

Create an interactive lesson on your computer and send it to the board wirelessly. You can also use the display as a collaborative digital whiteboard with images, videos, interactive measurement tools, pre-made activities, and templates.

Screen Share

Share up to 4 screens using the SMART Screen Share App or cast to the display using a device’s native screen sharing technology, like Chromecast. SMART Screen Share app features touchback control for Win and Mac devices.

Interactive Widgets and Simultaneous Tools

Increase engagement by using widgets such as Dice, Spinner, Clock, or Timer on top of any iQ content or video input. Plus, multiple students can perform separate tasks (ink, select, erase) at the same time with no interruptions.
